14x20 Gable Pavilion Plans

$9.99
$9.99
myoutdoorplans
0 ratings

If you want to build a beautiful 14x20 outdoor pavilion with a gable roof, these premium plans with step by step 3D diagrams and instructions will help you save time, money and get the job done in a weekend. This pavilion is built on a sturdy 6x6 framing, with 2x6 rafters every 24" on center. The pavilion also requires 6x8s for the support beams.

The pavilion features a gable roof with a 8:12 pitch and generous overhangs on all sides. Therefore the base of the pavilion has 14 ft x 20 ft. You can use pressure treated lumber for the pavilion, or invest in something weather resistant like cedar or redwood.

This makes for the perfect backyard shelter that can soon become your favorite spot, where you can relax, hang out with friends, serve dinner or read.

Just a few common tools are necessary, so you don't need a fully equipped and fancy workshop to start making projects!


*These are PREMIUM PLANS

*See full dimensions in the FEATURED IMAGES.




The PDF file comes with:

  • Cut Diagrams, Parts Lists
  • 3D diagrams with detailed step by step instructions
  • Full Cut & Shopping lists
  • Cut Layout Diagrams
  • Tools List, Time & Cost Estimate
  • Measurements are in imperial


All plans have been designed by Ovidiu D. It is your responsibility to made adjustments, if needed, to comply with the local codes. The plans are for personal use ONLY.

  • Size
    5.43 MB
  • Length
    16 pages
  • Size5.43 MB
  • Length16 pages
